Installer Reference

dspm-installer takes its settings from four places. A flag overrides an environment variable, an environment variable overrides the configuration file, and the configuration file overrides the built-in default. When the installer runs in a terminal, it prompts for any required value still missing; without a terminal, a missing required value is an error.

dspm-installer [flags]
dspm-installer wait-for-apps [flags]
dspm-installer upgrade --bundle-dir <path> [flags]
dspm-installer upgrade --download [flags]
dspm-installer upgrade --download --migrate [flags]
dspm-installer upgrade --connect [flags]
dspm-installer install-agent --server <url> --token <bundle> --name <name> [flags]
dspm-installer update-cert [flags]
dspm-installer rollback-cert [flags]
dspm-installer --help
dspm-installer --version

There are no single-letter flags.

Flags

Two environment variable names need care: --hostname reads DSPM_HOSTNAME, not HOSTNAME, because the shell sets HOSTNAME itself, and --assume-yes reads DSPM_ASSUME_YES, not ASSUME_YES.

Flag	Environment variable	Default	Description
--license-key	LICENSE_KEY	none	Netwrix license key. Required unless you pass --airgap. The installer validates it online before the install starts. Prefer the LICENSE_KEY environment variable: a flag value is visible in the process list.
--airgap	DSPM_AIRGAP	false	Install fully offline from the media at --bundle-dir, with no network calls and no license key needed at install time. Requires --bundle-dir. Mutually exclusive with --license-key, --local-charts-dir, and --use-mirrored-images, since air-gapped mode sources software and images from the media itself.
--bundle-dir	DSPM_BUNDLE_DIR	none	Path to the offline install media: the downloaded .tar.gz archive or an extracted directory. Required when you pass --airgap. Netwrix publishes media for both amd64 and arm64; download the media that matches the host's architecture, since the installer rejects media built for the wrong one. The installer reads the version and architecture from the archive's file name, so keep the name as downloaded.
--hostname	DSPM_HOSTNAME	none	Fully qualified domain name users open in their browsers. The installer lowercases it before use.
--first-admin-email	FIRST_ADMIN_EMAIL	none	Email address of the first administrator. Required. Becomes that person's username.
--first-admin-name	FIRST_ADMIN_NAME	none	Full name of the first administrator.
--tls-cert	TLS_CERT_FILE	/etc/dspm/tls.crt	PEM TLS certificate file, full chain with the leaf certificate first. Requires --tls-key.
--tls-key	TLS_KEY_FILE	/etc/dspm/tls.key	PEM TLS private key file. Requires --tls-cert.
--ca-bundle	TLS_CA_BUNDLE_FILE	none	PEM certificate authority (CA) bundle. Needed when a private CA issued the certificate.
--generate-self-signed-cert (alias --self-signed)	DSPM_GENERATE_SELF_SIGNED_CERT	false	Generate a one-time self-signed certificate and key pair at the resolved TLS paths instead of requiring one on disk. Requires --hostname. The installer only generates a certificate when none already exists at those paths — it never overwrites an existing one — and skips this under --dry-run.
--tls-cert-validity-days (alias --cert-days)	DSPM_TLS_CERT_VALIDITY_DAYS	365	Validity period, in days, for a certificate --generate-self-signed-cert generates. Maximum 36500.
--cert-manager-issuer-mode (alias --issuer-mode)	CERT_MANAGER_ISSUER_MODE	none	Hand issuance and renewal of the dspm-tls certificate to cert-manager instead of managing it yourself: none, selfsigned, adcs, or acme. See Automatic TLS Certificates for the acme mode. The installer doesn't save this to /etc/dspm/installer.yaml — see Configuration File.
--size	SIZE	medium	Deployment size: small, medium, large, or enterprise. Case-insensitive. See Size for the CPU, RAM, and disk each size requires.
--target-revision	TARGET_REVISION	1.*	Release version to install, such as 1.5.0. The default installs the latest 1.x release. The installer refuses a release older than itself and exits with code 16. Also appears as Target Revision under Show advanced settings?.
--progress	DSPM_PROGRESS	auto	Download progress style: auto, bar, ascii, or lines. Also applies to upgrade. See Download progress.
--storage-dir	DSPM_STORAGE_DIR	/var/lib	Directory holding everything the Kubernetes platform writes: container image layers, the server datastore, and every persistent volume. Set it at install time only. It also moves the install media to <dir>/dspm/media. Also appears as Storage Directory under Show advanced settings?. See Install media.
--accept-warnings	ACCEPT_WARNINGS	false	Continue past preflight warnings without asking.
--assume-yes	DSPM_ASSUME_YES	false	Skip the review screen that appears when the configuration file already supplies every required value.
--dry-run	DRY_RUN	false	Print the planned actions and exit without installing. Needs no TLS files and writes no configuration file.
--log-level	LOG_LEVEL	info	Detail the installer writes to the log file: debug, info, warn, or error.
--log-path	LOG_PATH	/var/log/dspm-installer.log	Path to the installer's log file. If you set this explicitly (flag, environment variable, or configuration file) and the path isn't writable or is a symlink, the installer stops with an error instead of falling back to the terminal.
--storage-dir	DSPM_STORAGE_DIR	/var/lib	Directory holding everything the Kubernetes platform writes: container image layers, the server datastore, and every persistent volume. Set it at install time only. Also appears as Storage Directory under Show advanced settings?. See Storage Location.
--postgres-data-dir	POSTGRES_DATA_DIR	none	Custom directory for the application database's data.
--clickhouse-data-dir	CLICKHOUSE_DATA_DIR	none	Custom directory for the analytics store's data.
--log-exports-storage	LOG_EXPORTS_STORAGE	none	Persistent volume claim (PVC) size for log exports, such as 10Gi.
--skip-preflight	SKIP_PREFLIGHT	false	Skip the preflight checks. For testing only.
—	DSPM_MEDIA_INSTALL	on	Set to false to install from the Netwrix registry instead of downloaded media.
--preflight	DSPM_PREFLIGHT	false	Run the preflight checks only, then exit without installing. See Preflight-only mode.
--version	—	—	Print the installer version and exit.
--help	—	—	Print flag help and exit.

The defaults for --tls-cert and --tls-key apply only when you omit both flags. Supplying one without the other is an error: --tls-cert and --tls-key must both be provided together.

Storage Location

By default, everything the Kubernetes platform writes lands under /var/lib/rancher/k3s: extracted container image layers and every container's writable layer, the server datastore, and, under storage/, every persistent volume in the cluster (PostgreSQL, ClickHouse, NATS, Redis, Prometheus, Metabase, log exports, and PostgreSQL backups). The image layers alone take about 13 GB, and the volumes then grow toward the disk figure for the chosen --size.

--storage-dir replaces /var/lib, so the whole tree moves to a mount you choose and you don't have to add space to /var/lib:

sudo dspm-installer \
  --license-key "$LICENSE_KEY" \
  --hostname dspm.corp.example.com \
  --storage-dir /data

This puts the platform's data directory at /data/rancher/k3s and the volumes at /data/rancher/k3s/storage. The rancher/k3s tail mirrors the default layout and means the installer owns a subdirectory of your mount rather than the mount itself, so --uninstall can clean up completely without touching anything else you keep on /data.

• The directory doesn't need to exist, but some ancestor of it must. The installer accepts --storage-dir /data/dspm/storage when only /data exists and rejects the path when nothing above it does. A mistyped path whose volume isn't mounted would otherwise fill the root filesystem, which is the problem this flag exists to avoid.
• The installer rejects some paths. The path must be absolute and can't be /. It can't be, or sit under, /bin, /sbin, /boot, /dev, /etc, /lib, /lib64, /proc, /root, /run, /sys, /usr, or /var/log, so /usr/local/dspm and /root/dspm both fail. It can't contain quotes, backslashes, $, spaces, tabs, newlines, or the characters *, ?, [, and ]. The nearest existing ancestor must be a directory the installer can write to.
• A small residual stays on /var/lib. The platform hardcodes the kubelet root at /var/lib/kubelet, so pod-local emptyDir volumes and rotated container logs under /var/log don't move. The charts cap each workload's ephemeral storage at 2 GiB, so preflight only warns when /var/lib has less than 10 GB free, while free space on the storage mount is a hard requirement.
• Set it at install time. On a server that already has a cluster, the installer compares --storage-dir with the directory the cluster uses. If they differ, it exits with code 21 and changes nothing. That includes re-running a relocated install without --storage-dir, because the default /var/lib no longer matches. The check is best-effort and doesn't run when the installer can't read the installed data directory. Without it, pointing an existing install at a new directory wouldn't migrate anything: the platform would come up as a new, empty cluster and leave every volume, secret, and database stranded at the old path. To move deliberately, run --uninstall first, then install again with the new --storage-dir.
• --uninstall deletes it. The uninstall removes the relocated data directory and its volumes but leaves the --storage-dir parent itself in place. It preserves any directory that's a mountpoint, so it can leave the tree behind; the installer checks afterward and names the path if it survived instead of reporting a clean uninstall.
• --postgres-data-dir and --clickhouse-data-dir are independent. Each replaces one service's volume with a static host-path volume, so a service with its own directory doesn't use the storage directory at all. --uninstall leaves those directories behind and says so.

The interactive wizard asks for the value under Show advanced settings? as Storage Directory, and the installer saves it to the configuration file as storage-dir, so re-runs keep it.

Advanced Flags

These flags control the underlying Kubernetes platform, ArgoCD, and Helm chart the installer manages. Most installs never need them — they exist for troubleshooting, custom environments, and uninstalling.

Flag	Environment variable	Default	Description
--k3s-version	none	v1.33.4+k3s1	K3s version to install.
--k3s-name	none	dspm	K3s service and instance name.
--kubeconfig	KUBECONFIG	/etc/rancher/k3s/k3s.yaml	Path to the kubeconfig file.
--argocd-version	none	3.2.0	ArgoCD image tag.
--argocd-namespace	none	argocd	Kubernetes namespace for ArgoCD. A media install doesn't support a non-default value.
--argocd-reconciliation-timeout	none	1h	How often ArgoCD self-heals configuration drift. The version-poller CronJob detects new releases separately.
--disable-dex	none	true	Disable the Dex identity provider.
--disable-notifications	none	true	Disable the ArgoCD notifications controller.
--helm-namespace	none	default	Kubernetes namespace for the Helm chart.
--helm-values	none	none	Path to a Helm values YAML file.
--chart	none	none	Chart name, for custom chart sources.
--repo	none	none	Helm repository URL, for custom chart sources.
--release	none	none	Helm release name, for custom chart sources.
--local-charts-dir	LOCAL_CHARTS_DIR	none	Mount a local Helm chart directory into argocd-repo-server and install from it with a file:// source, instead of a remote repository.
--use-mirrored-images	none	true	Pull container images from the Netwrix mirror registry. A media install rejects this flag.
--set	none	none	Inline Helm value override in key=value form. Repeatable.
--uninstall	DSPM_UNINSTALL	false	Uninstall k3s and permanently delete all Access Analyzer data. Prompts for confirmation unless you pass --force.
--force	DSPM_FORCE	false	Skip the confirmation prompt for --uninstall.
--tmp-dir	DSPM_TMP_DIR	none	--help doesn't list this flag. Moves the install media to <dir>/dspm/media, and the directory the offline package manager expands the media into, off the --storage-dir volume. Takes priority over --storage-dir for both. Unlike --storage-dir, it accepts /dev/shm, so a host with RAM to spare can expand the media in memory. The air-gapped disk check suggests --tmp-dir /dev/shm when that's the case. See Install media.

A custom data directory must be an absolute path to an existing, writable directory. It can't be /, can't sit under /bin, /sbin, /boot, /dev, /etc, /lib, /lib64, /proc, /root, /run, /sys, /usr, or /var/log, and can't contain quotes, backslashes, dollar signs, or backticks.

Certificate Manager Flags

The installer only reads the following flags when --cert-manager-issuer-mode selects the matching mode: the Automatic Certificate Management Environment (ACME) flags apply to acme, and the Active Directory Certificate Services (AD CS) flags apply to adcs. See Automatic TLS Certificates for acme and selfsigned, and AD CS TLS Certificates for adcs.

Flag	Environment variable	Default	Description
--acme-email	ACME_EMAIL	none	Email address for the ACME account. Required in acme mode.
--acme-server	ACME_SERVER	Let's Encrypt production	ACME directory URL. Point this at a private ACME certificate authority (CA) for internal issuance.

Flag	Environment variable	Default	Description
--adcs-url	ADCS_URL	none	The Active Directory Certificate Services (AD CS) server's /certsrv web enrollment endpoint URL. Required in adcs mode.
--adcs-username	ADCS_USERNAME	none	NT LAN Manager (NTLM) enrollment account for the AD CS server. Required in adcs mode.
--adcs-password	DSPM_ADCS_PASSWORD	none	Password for --adcs-username. Required in adcs mode. The installer never persists it to the configuration file or logs it.
--adcs-template	ADCS_TEMPLATE	WebServer	Certificate template to request from the AD CS server.
--adcs-ca-bundle	ADCS_CA_BUNDLE	none	PEM bundle for TLS to the AD CS server itself. This is separate from --ca-bundle, which covers Access Analyzer's own certificate chain.

warning

Set Extended Protection for Authentication (EPA) on the AD CS server's /certsrv endpoint to Off or Allow, not Required. The adcs issuer authenticates over NTLM without channel-binding tokens, so a /certsrv endpoint that requires EPA rejects every enrollment attempt with HTTP 401.

note

cert-manager's certificate signing request carries only Common Name and Organization in the subject. If the AD CS certificate template you name with --adcs-template requires Organizational Unit, Country, State, or Locality, AD CS rejects the enrollment.

There's no interactive wizard step for adcs mode — configure it with flags only.

Value Checks

The installer rejects bad values before it changes anything on the server.

Value	Rules
License key	Letters, digits, hyphens, and underscores only. The installer checks it online; an expired, suspended, unknown, or invalid key stops the install with exit code 10. If the installer can't reach the licensing service, it warns and continues.
Hostname	Must contain a dot, must not be an IP address, must not end in .localhost, and must not exceed 253 characters. Each dot-separated part is 1 to 63 letters, digits, or hyphens and can't start or end with a hyphen.
First administrator email	A plain address such as admin@corp.example.com, with a dotted domain and without a display name, quotes, backslashes, or spaces. The installer lowercases it before use.
TLS certificate and key	PEM. The pair must match, the certificate must not be expired, and its Subject Alternative Names must include the hostname. A certificate that expires within 30 days produces a warning in the log.
CA bundle	PEM with at least one certificate. The TLS certificate must chain to it. If the TLS certificate is self-signed and you give no bundle, the installer uses the certificate as its own bundle.

Configuration File

The installer keeps its answers in /etc/dspm/installer.yaml. It writes the file itself: after every confirmed prompt in an interactive run, or once after license validation in a flag-driven run. On the first save it prints Progress saved to /etc/dspm/installer.yaml — future runs will pre-fill these values. A later run reads the file and asks only for what's still missing, so a canceled install resumes where it stopped.

Keys are the flag names. The installer writes license-key, hostname, first-admin-email, first-admin-name, tls-cert, tls-key, and ca-bundle, plus target-revision when you pin a version other than 1.* and storage-dir when you set one other than /var/lib. It keeps any keys you add, and never saves operational flags such as --accept-warnings, --assume-yes, --dry-run, --skip-preflight, --preflight, and --cert-manager-issuer-mode. You can also write the file by hand before the first run.

/etc/dspm/installer.yaml

license-key: XXXX-XXXX-XXXX-XXXX-XXXX-V3
hostname: dspm.corp.example.com
first-admin-email: admin@corp.example.com
first-admin-name: Alice Smith
tls-cert: /etc/dspm/tls.crt
tls-key: /etc/dspm/tls.key
ca-bundle: /etc/dspm/ca-bundle.pem

The file holds the license key, so the installer creates it owned by root with mode 0600 inside a 0755 directory. A later run without sudo can't read it; the error ends with re-run with sudo, or remove the file. If /etc/dspm/installer.yaml doesn't exist, the installer also looks for ~/.dspm/installer.yaml. --dry-run never writes the file.

When the file supplies every required value and the installer runs in a terminal, it first asks Show advanced settings? (the default is No), then shows the review screen and asks Everything look good? before it starts. Declining the review prints Config file /etc/dspm/installer.yaml was loaded — edit or delete that file, or override individual values with flags. Pass --assume-yes to skip both questions.

Exit Codes

Code	Meaning
0	Success.
1	General failure: an invalid flag value, a hostname or TLS validation error, a required value missing in a non-interactive run, or you canceled the prompts with Esc or Ctrl-C (installation cancelled).
10	License key error. The key is expired, suspended, unknown, or invalid.
15	The installer rejected the air-gapped flags, or couldn't load the media: --airgap without --bundle-dir, --bundle-dir without --airgap, or media with no valid manifest.json. Also, this host already has a registry install. Use sudo dspm-installer upgrade --download --migrate instead.
16	A precondition failed and nothing changed, such as too little free space for the media, or a release older than the installer.
17	Connected installs only. The installer couldn't download, verify, or unpack the media. Run the command again to resume.
20	Connected installs only. The release version you requested with --target-revision isn't available for this license key, or the release has no media for this architecture.
21	This server already has a cluster, and --storage-dir differs from the directory it uses. That includes re-running a relocated install without passing --storage-dir again. The installer changed nothing. See Storage Location.
50	The installer couldn't install the platform, or the platform didn't become ready within 5 minutes.
60	The installer couldn't install a platform component.
70	The Access Analyzer services didn't all become healthy within 30 minutes, or you pressed Ctrl-C while waiting for them.
71	A service stayed in a failed state for 5 minutes. Only wait-for-apps returns this code; during an install the same condition exits 70.
80	Preflight checks failed (preflight checks failed), or you didn't accept warnings (preflight warnings detected; use --accept-warnings to continue or installation stopped at preflight warnings).

The upgrade, update-cert, and rollback-cert commands return their own codes. See The upgrade command, The update-cert command, and The rollback-cert command.

Preflight Checks

The following checks run before the installer changes anything on the server, in the order the table lists them. Which disk checks run depends on the install: a connected install adds media-disk, and setting --storage-dir adds kubelet-disk. Each ends as PASS, WARN, or FAIL. The installer prints only WARN and FAIL results, as [FAIL] <check> <message> or [WARN] <check> <message>. Any FAIL stops the install; --accept-warnings doesn't override it. Any WARN stops it too unless you answer Yes to Continue despite these warnings? or pass --accept-warnings.

The installer compares RAM and disk against their thresholds with a 5% tolerance, so a virtual machine provisioned at exactly the stated figure passes. It compares CPU cores exactly.

Check	What it tests	Result when not met	Message
ram	Total RAM against the minimum for the chosen size.	FAIL	<n> GB RAM; the <size> size requires <n> GB
cpu	CPU cores against the minimum for the chosen size.	FAIL	<n> CPU cores; the <size> size requires <n>
disk	Free space on the storage volume (--storage-dir, or /var/lib by default) against the 40 GB floor. The installer measures the nearest existing parent, since it creates the directory itself during install.	FAIL	<n> GB free on <path>; at least 40 GB is needed to install
disk	Free space on the storage volume against the size's recommended disk.	WARN	<n> GB free on <path>; the <size> size is designed to hold <n> GB, so it will run out as data accumulates
kubelet-disk	Runs only with --storage-dir. Free space on /var/lib against 10 GB, because the platform keeps pod-local storage there wherever the storage directory points.	WARN	<n> GB free on /var/lib; kubelet keeps pod-local storage there whatever --storage-dir is set to…
media-disk	Connected installs only. Free space for the install media, about 16 GB, on the volume that holds the media directory.	WARN	<n> GB free on <path>; the install media is downloaded and expanded there and wants about 16 GB, checked exactly before the download — point --tmp-dir or --storage-dir at a larger volume
cgroups	The kernel exposes cgroups at /sys/fs/cgroup.	FAIL	cgroups not available at /sys/fs/cgroup
kernel-modules	The kernel has the br_netfilter and overlay modules loaded or built in. The install loads missing modules itself, so this check warns only when it can't inspect a module, or during a dry run when a module isn't loaded.	WARN	kernel module issues: <module>: could not check module: <error> or kernel module issues: <module>: not loaded (dry run; will not be modprobed)
os	The Linux distribution belongs to a recognized family.	WARN	unrecognised Linux distribution; installation may not be supported
selinux	SELinux isn't in enforcing mode.	WARN	The message says SELinux is enforcing and asks you to allow the platform's container policy or set SELinux to permissive.
antivirus	The server has no known antivirus product installed or running: mdatp, CrowdStrike, ClamAV, Sophos, Carbon Black, or Trend Micro.	WARN	antivirus software detected: <product> (exclusion hint: <hint>)
network	Each required host resolves in DNS and accepts a connection on port 443 within 5 seconds. The hosts are api.keygen.sh and the media download host. On an SELinux-enforcing host, the check also tests api.github.com and rpm.rancher.io.	FAIL when a name doesn't resolve; WARN when a connection times out or the host refuses it	DNS resolution failed for: <hosts> or connection failed (timeout/refused) for: <hosts>
domain-join	Whether the server belongs to an Active Directory domain. Informational only.	—	no AD domain detected, or a message naming the detected domain
clock-sync	A time-sync service (chronyd, ntpd, or systemd-timesyncd) is running.	WARN	no clock sync daemon detected; Kerberos authentication requires clocks within 5 minutes of the AD domain controller — install chronyd, ntpd, or systemd-timesyncd to eliminate clock-skew risk

When the antivirus check finds a product, add these paths to that product's exclusion list: <storage-dir>/rancher/k3s/agent/containerd, <storage-dir>/rancher/k3s/data, and /run/k3s/containerd. <storage-dir> is /var/lib unless you set --storage-dir. See Storage Location. The hint in the message names the product's own command or console for adding exclusions.

The Requirements page lists the hosts the network check connects to and the CPU, RAM, and disk figures for each size.

Preflight-only mode

Pass --preflight to run the preflight checks and exit, without installing k3s, creating the cluster, or writing a configuration file. Use it to validate a server before you commit to an install.

Unlike an install, --preflight prints every check, including the ones that pass. In this example, a server checked against the small size passes every check but two warnings, so the command exits with code 80:

sudo dspm-installer --preflight --hostname dspm.corp.example.com --size small

--preflight runs the same checks this section lists, plus a certificate check: the PEM certificate and key at the resolved TLS paths must exist, match, and not be expired. A certificate expiring within 30 days still passes, because a real install would also proceed on it. Pass --hostname to also verify the certificate's Subject Alternative Names cover it, and --size to check RAM, CPU, and disk against the size you intend to install. Under --dry-run, the installer skips the certificate check, matching a dry-run install.

You can't combine --preflight with --uninstall or --skip-preflight. It writes the same /var/log/dspm-installer.log and /var/log/dspm-preflight.json files a regular install writes, except under --dry-run, where the installer doesn't write the JSON report.

Pass --airgap and --bundle-dir <path> along with --preflight to check an offline host. The installer runs the same checks, except it skips the network check, since an air-gapped host can't reach anything.

Code	Meaning
0	Every check passed, or the installer raised only warnings and you passed --accept-warnings.
80	A check failed, or the installer raised warnings and you didn't pass --accept-warnings.
1	You combined --preflight with --uninstall or --skip-preflight, or the checks themselves couldn't run.

RHEL and CentOS Preparation

Complete these steps on a Red Hat Enterprise Linux (RHEL) or CentOS server before you run the installer.

RHEL 10

RHEL 10 splits a kernel module the platform needs into a separate package. Install it first:

sudo dnf install -y kernel-modules-extra

Without it, the kernel-modules preflight check can't load br_netfilter or overlay.

Firewalld

Turn off firewalld:

systemctl disable firewalld --now

To keep it enabled instead, add these rules before you install:

firewall-cmd --permanent --add-port=6443/tcp
firewall-cmd --permanent --zone=trusted --add-source=10.42.0.0/16
firewall-cmd --permanent --zone=trusted --add-source=10.43.0.0/16
firewall-cmd --reload

These open the platform's internal API port and trust its pod and service networks. Also open the ports that Requirements lists for Access Analyzer itself.

Older RHEL and CentOS Releases

RHEL and CentOS releases before 8.4 ship a version of NetworkManager with a bug that interferes with the platform's networking. Disable nm-cloud-setup and reboot before you install:

systemctl disable nm-cloud-setup.service nm-cloud-setup.timer
reboot

The wait-for-apps Command

wait-for-apps repeats the readiness wait without reinstalling anything. Use it when an install stopped while waiting for the services, or to check whether they're all ready.

sudo dspm-installer wait-for-apps

It prints Waiting for applications to become Synced and Healthy… and exits when every service is healthy. On a server whose services are already healthy, it exits at once with code 0:

Flag	Default	Description
--timeout	30m0s	Maximum time to wait.

Exit codes: 0 when everything is healthy, 70 when the timeout passes, 71 when a service stays in a failed state for 5 minutes, and 1 for any other error. Ctrl-C exits 1.

The upgrade Command

upgrade moves an install to a newer release. It has four forms.

Form	Use it to
upgrade --download	Download the release's media from Netwrix and upgrade a connected install.
upgrade --bundle-dir <path>	Upgrade from media you downloaded, such as on an air-gapped install.
upgrade --download --migrate	Convert a registry install onto downloaded media.
upgrade --connect	Connect an air-gapped install so it can download upgrades.

Pass exactly one of --bundle-dir or --download, except for --connect. A bare upgrade exits with code 16.

An upgrade loads the new release's charts and container images into the cluster, applies the bundled ArgoCD manifest and the installer's ArgoCD overlay, re-seeds the registry pull secret into every application namespace, re-pins the netwrix ArgoCD application to the new version, and waits for every application to become Synced and Healthy. It records the previous version in the dspm.netwrix.com/previous-target-revision annotation on the netwrix application. See Upgrade to a New Version for the full procedure, including the media download and rollback, and Convert or Connect an Install for --migrate and --connect.

sudo dspm-installer upgrade --download
sudo dspm-installer upgrade --bundle-dir /etc/dspm/media/dspm-airgap-media-v<version>-<arch>.tar.gz

Run it with the dspm-installer binary from the release you're upgrading to. It doesn't run the prompts, preflight checks, or platform setup. It upgrades the Access Analyzer services and ArgoCD but not the k3s platform or the offline package manager. If the media targets a different version of either, it prints a warning that names both versions and continues with the installed ones.

Before it changes anything, it checks that the kubeconfig reaches a cluster with a netwrix application installed from offline media, that automated sync is on for that application, and that the release is newer than the installed one. A registry install needs --migrate first, or dspmctl as Upgrade to a New Version describes.

Flag	Environment variable	Default	Description
--download	none	false	Download the release's media instead of reading --bundle-dir. Needs a license key.
--bundle-dir	DSPM_BUNDLE_DIR	none	Path to the offline media of the release to upgrade to: the .tar.gz archive or an extracted directory.
--target-revision	TARGET_REVISION*	newest stable	Release to upgrade to. Needs --download.
--license-key	LICENSE_KEY	the saved key	License key. Needs --download.
--migrate	DSPM_UPGRADE_MODE=migrate	false	Convert a registry install onto downloaded media. Needs --download.
--connect	none	false	Connect an air-gapped install. Takes only the license key, --dry-run, --kubeconfig, and --timeout.
--in-cluster	DSPM_IN_CLUSTER	false	Run as the in-cluster upgrade Job. The app uses this flag. Don't run it on the host.
--tmp-dir	DSPM_TMP_DIR*	none	Where to keep the media.
--allow-downgrade	DSPM_ALLOW_DOWNGRADE*	false	Accept a release equal to or older than the installed release, for a redeploy or an intentional downgrade.
--progress	DSPM_PROGRESS	auto	Download progress style: auto, bar, ascii, or lines.
--dry-run	none	false	Validate the media and preconditions, check free space, and print the planned changes without changing the cluster or downloading anything.
--timeout	none	30m0s	Maximum time to wait for applications to become healthy after the re-pin.
--cert-manager-issuer-mode	none	none	Pass adcs to force re-seeding the registry pull secret into the adcs-issuer namespace. Usually unnecessary, because the command detects that namespace on its own.
--kubeconfig	KUBECONFIG	/etc/rancher/k3s/k3s.yaml	Path to the kubeconfig file.
--argocd-namespace	none	argocd	Kubernetes namespace for ArgoCD.

* Only the in-cluster Job reads this variable. On the host, pass the flag.

Code	Meaning
0	The cluster runs the new release and every application is Synced and Healthy, or the cluster already runs the newest release.
1	Unexpected error.
10	Netwrix rejected the license key.
15	The command couldn't load or deploy the media, and the cluster is still on the previous release. With --migrate, the command also exits with this code when an agent node runs on a different CPU architecture from the server. Run the command again after you fix the cause.
16	A precondition failed. Nothing changed.
17	The command couldn't download, verify, or unpack the media. Nothing changed. Run the command again to resume.
20	No release matches --target-revision, or the release has no media for this architecture.
60	The command couldn't apply the new version or the switch to the in-cluster source, or couldn't turn automated sync back on. Run sudo dspmctl enable-auto netwrix.
70	The new version applied but didn't become healthy in time. Run sudo dspm-installer wait-for-apps, or roll back.
71	A pod failed to start.

Check Upgrade Status

Each upgrade records its progress in the media-upgrade-status ConfigMap in the argocd namespace:

sudo kubectl -n argocd get configmap media-upgrade-status -o jsonpath='{.data.status}' | jq

The output shows the state (running, succeeded, or failed), the phase, the target and previous versions, the exit code, a one-line message, and the start and finish times.

The install-agent Command

install-agent joins the host you run it on to an existing installation as an agent node. You don't write the command by hand: the Deploy agent panel generates it with a registration bundle, as Deploy an agent describes. Run it as root on a separate Linux host, not on the Access Analyzer server.

sudo dspm-installer install-agent \
  --server=https://aa.corp.example.com:6443 \
  --token=<registration-bundle> \
  --name='Edge agent' \
  --label=region=eu

The bundle expires 30 minutes after the panel generates it, and install-agent refuses a bundle with less than 10 minutes left. The --token value is visible in the process list while the command runs, and a bundle for a server that isn't air-gapped contains the license key. Treat the command as a credential.

Flag	Environment variable	Default	Description
--server	none	none	Required. The Kubernetes API server URL that the host joins, such as https://aa.corp.example.com:6443. It overrides the address in the bundle. It isn't the URL of the web application.
--token	none	none	Required. The registration bundle from the Deploy agent panel.
--name	none	none	Required. The agent's display name.
--label	none	none	An agent label as key=value. Repeat the flag for more labels.
--bundle-dir	none	none	Offline media already on the host: the extracted directory, or the dspm-airgap-media-v<version>-<arch>.tar.gz archive, which the installer unpacks. Required for a server installed with --airgap. Refused for a server that pulls from the registry. Without it, an agent for a connected media install downloads the media.
--accept-warnings	none	false	Continue past preflight warnings without the prompt.

Before it changes the host, install-agent stops if the host runs the Access Analyzer server, if you don't run it as root, if the host's CPU architecture differs from the server's on a media install, or if the server's certificate doesn't cover the address in --server. It then runs the agent preflight, opens the firewall ports on a host that runs firewalld or ufw, and joins the host. On a media install, it downloads or unpacks the release's media first, keeps it in /var/lib/dspm/media, and deletes the media it unpacked or downloaded after the agent joins.

Check	Minimum
Memory	4 GB
CPU cores	2
Free disk	5 GB. A media install needs about 7 GB for the media and its unpacked copy, and preflight warns below 8 GB.

Code	Meaning
0	The agent joined and registered under its name.
1	General failure, such as an invalid flag or bundle, an expired bundle, or a refusal listed in Deploy an agent.
10	License key error while downloading the media.
16	A precondition failed and nothing changed: too little free space for the media, or the media's k3s is newer than the server's.
17	The installer couldn't download, verify, or unpack the media. Run the command again to resume.
20	The release's media isn't available for this license key or this architecture.
80	Preflight failed, you didn't accept its warnings, or the installer couldn't open the host firewall for firewalld or ufw.

The update-cert Command

update-cert installs a new TLS certificate on a running Access Analyzer installation, without re-running the full installer. Use it to replace a certificate that's expiring or expired, to replace one that pods don't trust, or to swap a self-signed certificate for a CA-issued one.

sudo dspm-installer update-cert \
  --tls-cert /etc/dspm/tls.crt \
  --tls-key /etc/dspm/tls.key \
  --ca-bundle /etc/dspm/internal-root-ca.pem

update-cert validates the certificate and key pair, confirms the certificate's Subject Alternative Names cover the installed hostname, snapshots the certificate the cluster serves, applies the new certificate and CA bundle, restarts every workload that mounts the CA bundle, and verifies the result before it exits. See Rotate the TLS certificate for the full procedure, including how to roll back with rollback-cert.

Flag	Default	Description
--tls-cert	(required)	PEM certificate file, full chain with the leaf certificate first.
--tls-key	(required)	PEM private key file matching --tls-cert.
--ca-bundle	none	PEM CA bundle the certificate chains to. Required unless the certificate is self-signed.
--hostname	from /etc/dspm/installer.yaml	Hostname the certificate must cover.
--port	443	External HTTPS port for probing the certificate the cluster serves.
--timeout	30m0s	Time budget for the whole rotation. A rollback, if needed, gets its own budget of the same size.
--dry-run	false	Validate the certificate and print the plan without changing the cluster. Doesn't need cluster access.
--no-rollback	false	Leave the new certificate in place if verification fails, instead of restoring the previous one automatically.
--kubeconfig	/etc/rancher/k3s/k3s.yaml	Path to the kubeconfig file.
--argocd-namespace	argocd	Kubernetes namespace for ArgoCD.

If verification fails, update-cert restores the previous certificate from its snapshot—unless you passed --no-rollback, or it couldn't reach the ingress at all. It exits with a code that tells you what state the cluster is in:

Code	Meaning
0	update-cert applied and verified the new certificate.
1	A check failed before update-cert wrote anything. The cluster is unchanged.
72	Verification failed; update-cert restored and verified the previous certificate. update-cert also returns 72 when you pass --no-rollback (nothing restored) or when it can't load the saved snapshot.
73	Verification failed; update-cert restored the previous certificate but couldn't verify it.
74	Verification failed and update-cert couldn't apply the rollback.
75	update-cert couldn't reach the ingress, so it verified nothing and rolled nothing back. The new certificate is still in place.

The rollback-cert Command

rollback-cert restores a certificate from a snapshot update-cert saved during an earlier rotation. Snapshots live under /etc/dspm/cert-snapshots/, and Access Analyzer never prunes them automatically. Snapshots contain private key material. See Roll back a certificate for how to remove ones you no longer need.

sudo dspm-installer rollback-cert --latest

Flag	Default	Description
--list	false	List available snapshots: timestamp, hostname, leaf certificate fingerprint, and expiry. Doesn't need cluster access.
--latest	false	Restore the most recent snapshot.
--snapshot	none	Restore the snapshot at the given path, such as /etc/dspm/cert-snapshots/<timestamp>.
--hostname	from /etc/dspm/installer.yaml	Hostname the restored certificate must cover.
--port	443	External HTTPS port for verifying the restore.
--timeout	30m0s	Time budget for the restore.
--kubeconfig	/etc/rancher/k3s/k3s.yaml	Path to the kubeconfig file.
--argocd-namespace	argocd	Kubernetes namespace for ArgoCD.

--list, --latest, and --snapshot are mutually exclusive.

Code	Meaning
0	rollback-cert applied and verified the restore.
1	A check failed before rollback-cert wrote anything, such as combining mutually exclusive flags or naming a snapshot that doesn't exist.
73	rollback-cert applied the restore, but verification failed.
74	rollback-cert couldn't apply the restore.

Logs

For the logs of the Access Analyzer services themselves, and for support bundles, see View and export logs.

File	Contents
The --log-path file (default /var/log/dspm-installer.log)	Everything the installer does, as one JavaScript Object Notation (JSON) object per line, at the detail --log-level sets. The installer appends to the file on every run, with mode 0640, and rejects a symlink at that path. At the default path, a write failure is non-fatal and the installer sends the same output to the terminal's standard error as text instead; with --log-path set explicitly, the same failure stops the installer with an error.
/var/log/dspm-preflight.json	The full result of the most recent preflight run: timestamp, overallStatus, and a checks list with name, status, and message for every check, including the ones that passed. --dry-run doesn't write it.
