Overview

This section will give you an overview of Identity Manager's components, their requirements and constraints, and possible interconnection schemes. At the end of this section, you should be able to choose the installation setup that fits best your organization's needs.

Components and Data Flow​

Components & Data Flow

Components​

Identity Manager's solution includes at least three components.

1. Server​

One server handles all of Identity Manager's computing needs, internal database management and serves the UI as a web application accessible through a browser.

The SaaS offering hosts the Identity Manager Server in the Cloud. This means that the server needs not be installed within a Identity Manager SaaS installation.

2. Database​

One database stores Identity Manager's data.

With the SaaS offering, the Identity Manager Database is hosted in the Cloud and needs not be installed.

The port used to access the database depends on the database configuration and the connectionString set in the technical configuration. See the Network Configuration topic for additional information.

3. Agents​

One or several agents perform synchronization and provisioning to/from the managed systems.

Data flow​

Identity Manager needs the following data flows to be enabled:

  • The Server requires opening connections to the Database.

  • The Agents require opening HTTPS connections to the Server.

  • The Agents require accessing managed systems.

  • All end-users' browsers require opening HTTPS connections to the Server.

  • All end-users' browsers require accessing the authentication providers. See the Install the Server topic for additional information.

  • Some end-users' browsers require opening HTTPS connections to the Agents.

    These connections are used to launch Jobs or use the Reset Password capabilities of some connectors. This requirement only applies to a few specific administrator type profiles.

  • The Server and the Agent both need to access an SMTP server to Send Notifications .

SaaS vs. On-Premise​

Identity Manager comes in two flavors: SaaS and On-Premise.

  • The SaaS offering only requires the Agent to be installed on your organization network.
  • The On-Premise offering requires the Agent, the Install the Server, and the Install the Database to be installed.

See the Install the Agents topics for additional information.

Hosting Hardware​

Depending on the existing network infrastructure and constraints, Identity Manager's components can be organized in several ways.

Database and Servers​

The Identity Manager Database can be installed on the same workstation as the Identity Manager Server or run on a separate machine. The second approach is recommended.

Server and Agents​

The Identity Manager Server and the Agents can be spread between several workstations. See the Install the Agents topics for additional information.

Two scenarios unfold:

1. The server and agents are installed on separate workstations

This approach is useful when managed systems need to run on separate and isolated networks.

Server & Agents isolated

2. The Server and one Agent are installed on the same workstation

In that case, the Identity Manager Agent can run directly within the Identity Manager Server process. The hosting workstation would only host a Identity Manager Server process (with the integrated agent) and no separate agent needs to be installed. The database could be installed on the same workstation or on a separate one.

Server & Agent together

Authentication​

End-users will be able to access Identity Manager after authentication. Several authentication methods are available. See the Install the Server topic for additional information.

Email Server​

Identity Manager sends notifications to users by email. An email server will have to be set up for the Agent and the Server. See the Send Notifications topic for additional information.

Before you check out the installation steps, make sure that all the Requirements are met.

Architecture

This article dives deeper into Identity Manager's design principles. Security and flexibility are the main concerns of the architecture.

A Two-Tier Architecture​

Identity Manager is made of two parts:

  • The Identity Manager server operates the main process. It uses a dedicated database, serves the client side part of the web application and exposes its API.
  • The Identity Manager agent operates data exchange with the information system. It implements a specific API called by the web client application.

Agent and server are ASP.Net applications running on Windows. Identity Manager's database is a Microsoft SQLServer relational database.

Architecture

See the SaaS Environment topic for additional information on Netwrix Identity Manager (formerly Usercube) recommended architecture when working in a SaaS environment.

See the On-Premises Environment topic for additional information on Netwrix Identity Manager (formerly Usercube)' recommended architecture when working in an on-premises environment.

See how to Protect Agent/Server Communication .

Isolation Principle​

Identity Manager server has no direct access to the information system of the organization. It can be installed on an isolated network (typically in the cloud). Only the agent can read or write the information system. All exchanges between agent and server are operated through the HTTP protocol (HTTPS recommended in production).

Unidirectional Command Flow​

All reading or writing actions in the information system are initiated by the agent. Identity Manager server will never call the agent. The Agent periodically polls the server to gather the actions to process.

Tasks can run on the Server side or on the Agent side.

Tasks that run on the Server side are still executed by an Agent. This is the application of the one-way data flow principle. Agents can send commands to the Server to execute a Task through an HTTP request but the Server cannot command an Agent, hence isolating the sensitive Agents from the exposed Server.

As a result, each set of planned Tasks is assigned to a specific Agent, depending on the managed systems its Tasks relate to.

Agents also receive HTTP/HTTPS requests from the browser to allow authenticated end-users to launch jobs from the UI.

Authentication​

Identity Manager can authenticate users within an Active Directory domain or using an OpenID identity server. For development mode, Identity Manager implements a form-based authentication using a unique password for all users . See the End-User Authentication topic for additional information.

Multi-Agent Capability​

Multiple agents can be installed. This allows Identity Manager to operate in a context where the information system is partitioned over several networks.
